Models
200 H 500
300 H 730
300 H 950
300 H 1250
400 H 730
400 H 950
400 H 1250
ITEM OF CONTRACT SPECIFICATIONS
SELF-SUPPORTING SLOTTED CHANNELS MOD. Eurobeton …………..PRODUCED IN REINFORCED CONCRETE WITH LOAD CLASS …..(D400..F900)…ACCORDING TO STANDARD DIN EN 1433, RESISTANCE CLASS C 40/50 ACCORDING TO STANDARD DIN EN 206-1/ DIN 1045-2, CONCRETE EXPOSURE CLASS XF4 ACCORDING TO STANDARD DIN 1045-2 RESISTANT TO FREEZING AND THAWING ACCORDING TO STANDARD DIN EN 1433. LENGTH ELEMENTS 4000 mm. WITH HEIGHT OF mm………… WIDTH OF mm………….. AND SECTION INTERNA OF mm…..(200 – 200×300 – 300×400)….). WATERPROOF CONNECTION OF ELEMENTS WITH RUBBER GASKETS EMBEDDED IN THE FEMALE JOINT OF THE ELEMENTS.
ITEM OF CONTRACT SPECIFICATIONS (inspection shafts)
SPECIAL PIECE – INSPECTION SHAFT FOR SELF-SUPPORTING SLOTTED CHANNELS MOD. Eurobeton …………..PRODUCED IN REINFORCED CONCRETE WITH LOAD CLASS ….(D400 F900….) ACCORDING TO STANDARD DIN EN 1433, RESISTANCE CLASS C 40/50 ACCORDING TO STANDARD DIN EN 206-1/ DIN 1045-2, CLASS OF EXPOSURE OF THE CONCRETE XF4 ACCORDING TO STANDARD DIN 1045-2 RESISTANT TO FREEZING AND THAWING ACCORDING TO STANDARD DIN EN 1433.
LENGTH ELEMENTS 1000 mm. WITH HEIGHT mm………… WIDTH mm………….. AND INTERNAL SECTION mm…..(200 – 200×300 – 300×400)….). WATERPROOF CONNECTION OF ELEMENTS WITH RUBBER GASKETS EMBEDDED IN THE FEMALE JOINT OF THE ELEMENTS. UPPER GRID IN PIG-IRON BOLTED TO THE CHANNEL CLASS …(D400 F900…)
